450nm 1.4W Laser Diode For Lipo Laser Machine/Lipo Laser Slimming
Quick Details
Application:Laser rangefinder, confocal microscope
Place of Origin:China
Brand Name:XINLAND
Type:Laser Diode
Package Type:Surface Mount
Max. Forward Voltage:-
Max. Reverse Voltage:-
Max. Forward Current:-
Max. Reverse Current:-
Supply Ability
Supply Ability:15000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details:ASD-box
Port:Xi’an Shaanxi
Lead Time :
| Quantity(Pieces) | 1 - 200 | >200 |
| Est. Time(days) | 3 | To be negotiated |
Cautions
(1)Operating method
The LD shall change its forward voltage requirement and opca output power according to temperature change. Also, the LD will require more operation current to maintain same output power as it dedes.
Confirm that electrical spike current generated by switching on and off does not exceed the maximum operating current level specified herein above as absolute max rating. Also, employ appropriate countermeasures to reduce chattering and/or
ACC(Auto Current Control)mode is recommended for the Product operation. Also, please be careful for the overshooting in order to avoid excessive optical output power as the laser operation is started
(2) Static Electricity
Static electricity or electrical surges will reduce and degrade the reliability of the LDS. It is recommended to use a wrist strap or anti-electrostatic glove when handling the Product
(3)Absolute Maximum Rating
Active layer of LDS shall have high current density and generate high electric field during its operation. In order to prevent excessive damage, the LD must be operated strictly below Absolute Max Rating
