976nm~980nm 5W c mount laser diode Laser Pumping

Name: 976nm980nm 5W c mount laser diode Laser Pumping
Brand: XINLAND
Price: 1 USD

Buy cheap 976nm~980nm 5W c mount laser diode Laser Pumping product

Brand Name : XINLAND

Model Number : XLD-980-005-C

Certification : CE

Place of Origin : Xi’an Shaanxi China

MOQ : 100pcs

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000 Dozen/Dozens per Day

Delivery Time : 7 days

Packaging Details : 1pcs/polybag,10pcs/inner box,100pcs/ctn

Type : Laser Diode

Package Type : Through Hole

po(mW) max : 30MW

Top(C) : -10-60

po(mW) min : 30MW

Contact Now

976nm~980nm 5W Laser Diode With C-Mount Package Laser Pumping

Quick Details

Place of Origin:Xi’an Shaanxi China

Brand Name:XINLAND

Model Number: XLD-980-005-C

Type:Laser Diode

Package Type:Through Hole

po(mW) max:30MW

Top(C):-10-60

po(mW) min:30MW

Ith(mA):30mA

Iop(mA):50mA

Vop(v):2.3V

Supply Ability

Supply Ability:10000 Piece/Pieces per Month

Packaging & Delivery

Packaging Details:electrostatic bag

Port:Xi’an Shaanxi China

Lead Time :

Quantity(Pieces)	1 - 500	>500
Est. Time(days)	5	To be negotiated

Quick Details

Application:Laser rangefinder, confocal microscope

Place of Origin:China

Brand Name:XINLAND

Type:Laser Diode

Package Type:Surface Mount

Max. Forward Voltage:-

Max. Reverse Voltage:-

Max. Forward Current:-

Max. Reverse Current:-

Supply Ability

Supply Ability:15000 Piece/Pieces per Week

Packaging & Delivery

Packaging DetailsASD-box

Port:Xi’an Shaanxi

Lead Time :

Quantity(Pieces)	1 - 200	>200
Est. Time(days)	3	To be negotiated

Technical Parameter

	Min.	Type	Max.
Central Wavelength (@25 deg.C)	±5nm	976nm	±10nm
Spectral Width (FWHM)	------	3.0nm	------
Output power	------	5.0w	-------
Emitter Area		100x1μm
Temperature Coefficient of Wavelength		0.3nm / °C
Beam Divergence (FWHM)	------	35°┴ x 8°//
Slope Efficiency	-----	1.0W/A	--------
Threshold Current (Typ.)	----	0.3A	--------
Operating Current (Typ.)	-------	5.2A	---------
Operating Voltage	-------	1.6V	--------
Package Style	C-mount
Recommend Operating Temp	25 °C

976~980nm 5W Laser Diode with C-mount Package | FAC Optional 980nm High Power 5W LD | Square Beam Optional | Medical cure | Laser Pumping

976nm~980nm 5W c mount laser diode Laser Pumping

Product Tags:

980nm 5W Laser Diode

C Mount Laser Diode Laser

976nm~980nm 5W c mount laser diode Laser Pumping Images
